Fixed Wall Mount
Flat Panel Wall Mount for 37 to 86 inch
SKU 33FW001 · MPN 33FW001
Fixed wall mount for flat panels from 37 to 86 inches, rated to 140 lb. It holds the screen 1.25" from the wall. Fits VESA mounting patterns from 63 x 69 to 774 x 469 mm. Black powdercoat finish; mounting hardware is included.
Specifications
| Recommended screen size | 37 to 86 in |
|---|---|
| Weight capacity | 140 lb |
| Tilt | None (fixed) |
| VESA mounting range | 63 × 69 mm to 774 × 469 mm |
| Profile (distance from wall) | 1.25 in |
| Manufacturer | Expert AV Products, Inc. |
| Fits VESA standards (mm) | 75x75, 100x100, 200x100, 200x200, 300x300, 400x200, 400x300, 400x400, 400x600 |
Details
The mounting pattern adjusts in both width and height, which lets one bracket cover VESA hole patterns from 63 x 69 mm up to 774 x 469 mm; that span takes in most flat panel TVs and monitors in the 37 to 86 inch range. The display bolts to the mount through its rear VESA holes with the supplied hardware. Anchor the mount to wall structure, wood studs or masonry, that can carry the combined weight of mount and display; drywall alone will not hold a large panel.
As a fixed mount it has no tilt or swivel mechanism, so the panel sits close to the wall at a set angle. Position large screens at or near eye level for the audience, since the angle cannot be corrected later. The size range covers large-format displays in conference rooms, restaurants, lobbies, and digital signage installations. Never exceed the 140 lb rated capacity.
